Engineered and manufactured to endure the most difficult of environments and applications. Thermal Edge air conditioners will exceed environmental requirements in applications like Steel, Food Processing, Petro-Chemical, Cement, Paper and Pulp and Plastics. All products are available in UL types 12, 4 and 4X.
Enclosure Air Conditioners
50 Hz Enclosure Air Conditioners
Compact Series Enclosure Air Conditioners
DC Voltage Series Enclosure Air Conditioners
High Capacity Series Enclosure Air Conditioner
Narrow Edge Series Enclosure Air Conditioners
Top Mount Enclosure Air Conditioners
Compact Series Enclosure Air Conditioners
Small, but powerful, air conditioners still feature the same valuable features as the larger models.
| Model | BTU/H | Voltage / Phase / Hz | Running Amps | Max Ambient Temp °F | HxWxD | Weight (lbs) Unit / Ship |
|---|---|---|---|---|---|---|
| CS020126 | 2000 | 115/1/60 | 4.1 | 131°F | 20" x 10" x 10" | 44 / 58 |
| CS020236 | 2000 | 230/1/60 | 2.0 | 131°F | 20" x 10" x 10" | 49 / 63 |
| CS011126 | 1000 | 115/1/60 | 2.7 | 131°F | 17" x 7" x 7" | 30 / 43 |
DC Voltage Series Enclosure Air Conditioners
48 VDC for telecom outside plant, off-grid solar, wind, & other battery powered electrical cabinets. Same features as our AC powered units.
| Model | BTU/H | Voltage / Phase / Hz | Running Amps | Max Ambient Temp °F | HxWxD | Weight (lbs) Unit / Ship |
|---|---|---|---|---|---|---|
| NE040D48 | 4000 | 48 VDC | 25.3 | 131°F | 35.27” x 11.8” x 9.5” | 103 / 120 |
| CS011D48 | 1000 | 48 VDC | 3.7 | 125°F | 17” x 7” x 7” | 30 / 43 |
High Capacity Series Enclosure Air Conditioner
For demanding applications requiring 10,000 to 20,000 BTUH cooling capacities.
| Model | BTU/H | Voltage / Phase / Hz | Running Amps | Max Ambient Temp °F | HxWxD | Weight (lbs) Unit / Ship |
|---|---|---|---|---|---|---|
| HC121126 | 12000 | 115/1/60 | 19.4 | 131°F | 48" x 15.86" x 15.03" | 167 / 185 |
| HC121236 | 12000 | 230/1/60 | 8.2 | 131°F | 48" x 15.86" x 15.03" | 163 / 183 |
| HC121486 | 12000 | 460/1/60 | 4.1 | 131°F | 56.6" x 15.86" x 15.03" | 237 / 280 |
| HC151236 | 15000 | 230/1/60 | 11.3 | 131°F | 48" x 15.86" x 15.03" | 170 / 190 |
| HC151486 | 15000 | 460/1/60 | 5.7 | 131°F | 56.6" x 15.86" x 15.03" | 247 / 290 |
| HC201236 | 20000 | 230/1/60 | 13.7 | 131°F | 56.09" x 23" x 15.03" | 205 / 225 |
| HC201486 | 20000 | 460/1/60 | 6.9 | 131°F | 65.7" x 23" x 15.03" | 337 / 380 |
| HC101126 | 10000 | 115/1/60 | 19.4 | 131°F | 48" x 15.86" x 15.03" | 162 / 182 |
| HC101236 | 10000 | 230/1/60 | 8.2 | 131°F | 48" x 15.86" x 15.03" | 166 / 186 |
| HC101486 | 10000 | 460/1/60 | 4.1 | 131°F | 56.6" x 15.86" x 15.03" | 232 / 275 |
| Product Sheets | Machine Drawings | Cutout Templates (120/230v) | Cutout Templates (480v) | ||||
|---|---|---|---|---|---|---|---|
| Model | PDF File | PDF File | DWG File | PDF File | DWG File | PDF File | DWG File |
| HC101 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | PDF | DWG |
| HC121 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | PDF | DWG |
| HC151 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | PDF | DWG |
| HC201 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | PDF | DWG |
Narrow Edge Series Enclosure Air Conditioners
1000 to 8000 BTUH air conditioners that fit on 12″ deep enclosures.
| Model | BTU/H | Voltage / Phase / Hz | Running Amps | Max Ambient Temp °F | HxWxD | Weight (lbs) Unit / Ship |
|---|---|---|---|---|---|---|
| NE010126 | 1000 | 115/1/60 | 3.44 | 125°F | 22" x 11.8" x 8.5" | 51 / 65 |
| NE010236 | 1000 | 230/1/60 | 2.67 | 125°F | 22" x 11.8" x 8.5" | 53 / 67 |
| NE015126 | 1500 | 115/1/60 | 3.44 | 125°F | 22" x 11.8" x 8.5" | 51 / 65 |
| NE015236 | 1500 | 230/1/60 | 2.67 | 125°F | 22" x 11.8" x 8.5" | 53 / 67 |
| NE020126 | 2000 | 115/1/60 | 3.76 | 125°F | 32" x 11.8" x 9.5" | 65 / 79 |
| NE020236 | 2000 | 230/1/60 | 3.07 | 125°F | 32" x 11.8" x 9.5" | 72 / 86 |
| NE020486 | 2000 | 460/1/60 | 0.94 | 125°F | 38" x 11.8" x 9.5" | 99 / 113 |
| NE030126 | 3000 | 115/1/60 | 5.15 | 125°F | 32" x 11.8" x 9.5" | 66 / 80 |
| NE030236 | 3000 | 230/1/60 | 3.07 | 125°F | 32" x 11.8" x 9.5" | 72 / 86 |
| NE030486 | 3000 | 460/1/60 | 1.3 | 125°F | 38" x 11.8" x 9.5" | 99 / 113 |
| NE040126 | 4000 | 115/1/60 | 5.15 | 125°F | 32" x 11.8" x 9.5" | 66 / 80 |
| NE040236 | 4000 | 230/1/60 | 3.07 | 125°F | 32" x 11.8" x 9.5" | 72 / 86 |
| NE040486 | 4000 | 460/1/60 | 1.3 | 125°F | 38" x 11.8" x 9.5" | 99 / 113 |
| NE050126 | 5000 | 115/1/60 | 7.26 | 125°F | 36" x 11.8" x 15.02" | 97 / 111 |
| NE050236 | 5000 | 230/1/60 | 3.76 | 125°F | 36" x 11.8" x 15.02" | 92 / 106 |
| NE050486 | 5000 | 460/1/60 | 1.9 | 125°F | 44.63" x 11.8" x 15.02" | 136 / 150 |
| NE060126 | 6000 | 115/1/60 | 7.83 | 125°F | 36" x 11.8" x 15.02" | 97 / 111 |
| NE060236 | 6000 | 230/1/60 | 4.8 | 125°F | 36" x 11.8" x 15.02" | 98 / 112 |
| NE060486 | 6000 | 460/1/60 | 2.4 | 125°F | 44.63" x 11.8" x 15.02" | 142 / 156 |
| NE080126 | 8000 | 115/1/60 | 7.83 | 125°F | 36" x 11.8" x 15.02" | 97 / 111 |
| NE080236 | 8000 | 230/1/60 | 4.8 | 125°F | 36" x 11.8" x 15.02" | 98 / 112 |
| NE080486 | 8000 | 460/1/60 | 2.4 | 125°F | 44.63" x 11.8" x 15.02" | 142 / 156 |
| Product Sheets | Machine Drawings | Cutout Templates (120/230v) | Cutout Templates (480v) | ||||
|---|---|---|---|---|---|---|---|
| Model | PDF File | PDF File | DWG File | PDF File | DWG File | PDF File | DWG File |
| NE010 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | ||
| NE015 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | ||
| NE020 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | PDF | DWG |
| NE030 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | PDF | DWG |
| NE040 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | PDF | DWG |
| NE050 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | PDF | DWG |
| NE060 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | PDF | DWG |
| NE080 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | PDF | DWG |
Top Mount Enclosure Air Conditioners
Top Mount units are for use on enclosures with no room on the sides for an air conditioner.
| Model | BTU/H | Voltage / Phase / Hz | Running Amps | Max Ambient Temp °F | H x W x D | Weight (lbs) Unit / Ship |
|---|---|---|---|---|---|---|
| TM061126 | 6000 | 115/1/60 | 10.6 | 131°F | 15.6" x 26.3" x 20.2" | 111 / 163 |
| TM061236 | 6000 | 230/1/60 | 6 | 131°F | 15.6" x 30.6" x 20.2 | 111 / 163 |
| TM061486 | 6000 | 460/1/60 | 3 | 131°F | 15.6" x 30.6" x 20.2 | 154 / 206 |
| TM081126 | 8000 | 115/1/60 | 11.6 | 131°F | 15.6" x 26.3" x 20.2" | 111 / 163 |
| TM081236 | 8000 | 230/1/60 | 7 | 131°F | 15.6" x 30.6" x 20.2" | 111 / 163 |
| TM081486 | 8000 | 460/1/60 | 3.5 | 131°F | 15.6" x 30.6" x 20.2" | 154 / 206 |
| Product Sheets | Machine Drawings | Cutout Templates (120/230v) | Cutout Templates (480v) | ||||
|---|---|---|---|---|---|---|---|
| Model | PDF File | PDF File | DWG File | PDF File | DWG File | PDF File | DWG File |
| NE060 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | PDF | DWG |
| NE080 Enclosure Air Conditioner | PDF | PDF | DWG | PDF | DWG | PDF | DWG |
| TM061 Enclosure Air Conditioner | PDF | PDF | PDF | DWG | PDF | DWG |
|
| TM081 Enclosure Air Conditioner | PDF | PDF | PDF | DWG | PDF | DWG |
|
