Nemaco offers UL Listed Type 6 & Type 6P Enclosure Solutions per NEMA 250 and the UL 50/50E design specifications for product testing, routine inspections and quality-control standards. Nemaco designs junction boxes and control cabinets to withstand adverse weather conditions and water submersion. Call or send an email to Nemaco for product technical information and solutions.
Nemaco’s submersible enclosures are factory tested to ensure strong ingress protection—there is “NO WATER” inside any submersible cabinet when installed correctly per factory technical specifications, professional mechanical & plumbing standards and the National Electric Code (NEC).
Nemaco can offer the following hardware and water-seal options to customers:
Our waterproof enclosures are compatible with both NEMA and IP ratings: NEMA 6/6P and IP67/IP68.
Nemaco has factory quality control standard procedures on all waterproof enclosures manufactured and tested before shipping to customers. The basic standard requires that every enclosure is tested for a full 24 hours under simulated environmental conditions and inspected to have no leaks on the gaskets or any conduit hubs, pipe fittings or windows if applicable.
To learn more about Nemaco’s products, follow the links below.
We test all waterproof enclosure designs to pass NEMA 6 and 6P criteria of UL 50/50E and NEMA 250 standards, ensuring protection under 6 ft (1.8 m) of water for 24 hours.
Quality corrosion-resistant materials are used for the NEMA 6P rating. Each application might be different, and our team will work with you to select the right material.
Nemaco offers corrosion-resistant grades of stainless steel for NEMA 6/6P enclosures. Common grades include:
You might ask:
Type 316 contains more nickel, molybdenum and chromium than type 304, offering superior corrosion resistance (and higher cost). Choose 316 for salt-water or chemical exposures; choose 304 when corrosion risk is lower to save cost.
Choosing between these details can be tricky—contact the Nemaco team today.
Nemaco designs and manufactures submersible waterproof control cabinets using:
5052-H32 and 6061 are lightweight, thermally conductive and corrosion-resistant—ideal for telecom, lift stations, traffic control and water/wastewater treatment. Aluminum enclosures are easier to install and dissipate heat effectively. Ask Nemaco about powder-coat finishes.
To maximize longevity against harsh environments, Nemaco’s aluminum NEMA 6/6P enclosures are powder coated with UL-listed epoxy finishes in white, light grey, dark grey or black. Custom colors (hunter green, blue, yellow, orange, etc.) are available on request.
Contact us today with any questions to find the ideal solution for your project.
